Small baskets of size 500x500mm in section, either 2-4m long.

Why you need the Garden Gabion

The smaller Garden Gabion can be used at home for terracing and smaller Gabion retaining walls, or even internal feature/decorative walls, or raised garden beds as illustrated below. Generally the height of wall you require is 500 – 1000mm in height and this can easily be constructed using the 500 x 500 (width x height) basket. We offer hexagonal woven or weldedmesh for this purpose. Examples of both basket mesh types are shown below.

  1. The hexagonal woven mesh has an aperture of 80x100mm, with mesh wire diameter of 2.7mm, edge wire is 3.40mm.
  2. The square weldedmesh basket is supplied with an aperture of 50x100mm, wire diamter of 3.15mm

All Gabion mesh is Class A Galvanised mild tensile steel, to provide flexibility, and supplied packed flat for erection and filling on site. The small Gabion can be filled with glass bottles, rock, timber logs, building rubble, roof tiles or whatever you have available or would like to decorate the basket with, including filling with locally available topsoil. This soil filled basket would then require the Coir fiber blanket internally along all sides to prevent the loss of soil, lifespan of coir is 3-4years depending on the local climate. If filled with rock, the basket design life typically is 20-40 years, as long as not placed into an extremely corrosive environment. The PVC coated woven mesh is more suited to corrosive environments.

Recent Garden Gabion Job completed in Benoni:

Basket sizes available

0.5 x 0.5 x 0.5

1 x 0.5 x 0.5

2 x 0.5 x 0.5 or even

4 x 0.5 x 0.5
(length x width x height in metres)

Prices available on request.

What can the Garden Gabion be used for?

Revetment walls instead of large mass – gravity walls.
Gabion terracing steps.
Gabion Pillars.
Gabion Planter pots.

See Garden Gabion in Action



Gabions and river mattresses


Concrete retaining walls

Sports fields

Railway tracks

Behind concrete walls and Embankments

Provides waterproofing qualities for layer works and wearing courses

The separation of good and poor roadway layer work materials
roads over soft soils

Gabion structures
landfill sites



Request Quote

Request Quote

PRODUCT Request Quote cform Gabion



Do you do installations or supply only?
We can indeed offer specialist experienced installers, or supply an experienced trainer to site.
Do you offer technical training on your product and design application support?
We offer full technical product knowledge and PowerPoint technical training and presentations.
Do you visit site and offer advice?
We certainly can visit site, for which we charge a small fee to cover expenses for the site visit, full design (if required) and quotation.
Do you offer site practical support / training?
We visit sites we needed, for friendly advice and also offer full site practical training for our products.
Do you deliver products to sites with rock?
We can supply our range of products, including the whole range, with rock supplied separately to site, to make your buying process easier.
Do you have information on the correct applications and installation guidance for your products?
We have a few options for getting the knowledge to install our materials, having a YouTube website channel, called Gabionbaskets, where we show installation videos and animations as well as printed A4 sheets showing the correct installation process. For applications we show some on our website, kindly contact us for more information in this regard.
